Medical Grade Liquid Silicone Rubber

Medical grade liquid silicone rubber(LSR) is a liquid silicone raw material processed by injection process to make medical silicone products. It does not require secondary vulcanization and has excellent physical and mechanical properties, which not only saves production energy consumption and cost, but also improves production efficiency.

Hypoallergenic

FDA/ISO10993 certification
Excellent biocompatibility

Low MOQ：200KG

Get the free samples now!

What is Medical Grade Liquid Silicone Rubber(LSR)?

Liquid Silicone Rubbers Products

Medical grade LSR is an elastic liquid silicone rubber cured by platinum catalyst and high-purity two-component silicone rubber It is uniformly mixed in a static mixer below 30° and a low-temperature barrel, and then injected into the mold through a nozzle. The mold temperature needs to be heated to above 140° (different sizes of products have different curing temperatures), the two-component material is inside the mold and a curing crosslinking reaction is carried out. The medical LSR produced by Yongrui can be used in medical devices and silicone products with short-term implantation of fewer than 29 days.

Why choose medical grade liquid silicone rubber?

In the 1960s, medical-grade LSR was gradually used in human implants and medical products. In particular, the application of medical silicone rubber in heart valves and pacemakers has brought new lives to thousands of patients. In addition, the emergence of medical silicone rubber has opened a new era for medical products. After the 1970s, medical LSR has been widely used in the medical field in many countries (laryngeal masks, silicone rubber breasts, breathing tubes, check valves, tracheal intubation, drainage tube, menstrual cup, peritoneal dialysis tube, shunting catheters with a balloon. , catheter, etc.) and put into clinical use. Due to the manufacturability of the raw materials, many medical industry manufacturers choose liquid silicone for their silicone parts. Injection molding of liquid silicone rubber allows businesses to process easy, high-volume molding, consistent part quality, and increase productivity.

☉ The vulcanization speed of medical LSR is fast, no two-stage vulcanization is required, and a rapid cross-linking reaction occurs under the action of high temperature and high pressure.

☉ Medical grade LSR adopts the injection molding process, which can carry out precise, efficient, and automatic injection molding production, and can produce parts with consistent quality in large quantities.
☉ For it is well suited for automation, it can limit contamination in cleanroom manufacturing operations. LSR also improves purity and biocompatibility compared to high-consistency rubber silicone.
☉ Medical grade LSR has excellent properties such as excellent biocompatibility. Even if the medical product is placed in the body for a short time, it will not cause rejection to the surrounding tissues of the body. It is very biologically adaptable and will not stick to the capillaries of the human body.
☉ In the process of use, it also needs to withstand high temperature, high pressure, and sterilization, and its performance is not affected. To meet the above requirements, medical grade LSR is the most suitable material for medical products.

Medical grade liquid silicone rubber application

Medical Grade liquid silicone rubber for catheter

Medical Grade LSR for catheter

It has the characteristics of aging resistance, good biocompatibility and stable performance. After decades of clinical use, it has been proved to be a safe and reliable medical material.

Metal self-adhesive liquid silicone rubber

Medical Grade LSR for gastric tube

It is used to manufacture flexible silicone gastric tube with excellent corrosion resistance.

Medical Grade silicone rubber liquid for tracheal intubation

Medical Grade LSR for tracheal intubation

The tracheal intubation injection molded from medical grade LSR is non-toxic, non-allergic, and has very little body rejection, which greatly reduces the adverse reactions of patients.

Medical Grade liquid silicone rubber for drain ball

Medical Grade LSR for drain ball

It has excellent biocompatibility, softness, good resilience, continuous and stable negative pressure, ensuring fast and thorough drainage and reducing clogging.

Medical Grade liquid silicone rubber for sealing ring

Medical Grade LSR for sealing ring

It is a kind of high environmental protection and high-temperature resistant silicone raw material. It is usually used to manufacture highly transparent sealing rings. It has a smooth surface, strong resilience, and good sealing performance.

Medical Grade liquid silicone rubber for menstrual cup

Medical Grade LSR for menstrual cup

It is a food-grade silicone material, soft and elastic, skin-friendly, non-toxic and tasteless, safe to use, and more environmentally friendly.

The unique properties of medical grade liquid silicone rubber

☉ Safe and reliable: It does not contain phthalic acid and has passed FDA and LFGB certifications.

☉ Good biocompatibility: It has excellent compatibility with human tissue and can maintain its original softness and elasticity during contact with human tissue without being degraded. It is FDA-compliant, resistant to bacterial growth, and will not contaminate or corrode other materials.

☉ Hypoallergenic: It is compatible with surrounding tissues, does not react with organisms, does not cause inflammation, and has as few foreign body reactions as possible; does not cause allergic reactions or surface coagulation; implanted in the body, short-term use does not lose tensile strength, elasticity, etc. Mechanical behavior;

☉ High chemical stability: It will not affect the performance after being subjected to harsh disinfection such as high pressure, boiling, gas, liquid medicine, etc.

☉ Strong high and low-temperature resistance: It will not deform at -60 ℃-300 ℃, still maintain good strength and elasticity, and will not produce decomposed harmful substances.

☉ Comfortable touch: Soft, good toughness, kink resistance, no deformation after bending;

More medical component applications

As a soft, skin-friendly, colorless, and odorless material, medical-grade LSR meets the US FDA food and drug testing standards and belongs to the medical grade. Medical liquid silicone itself has many unique properties such as good physiological inertness, good wear resistance, high elasticity, resistance to body fluid corrosion, aging resistance under harsh environmental conditions, and no inflammation of human tissue. Therefore, it has been widely used in the medical field, such as laryngeal masks, bronchial intubation, Hollow Throat Tube, analgesia pumps, infusion pumps, medical Air Bag, electronic pump infusion tubes and so on.

Why choose our medical grade LSR as the material for your medical parts?

Professional

12 years experience in medical liquid silicone material
OEM/ODM

All kinds of viscosity, hardness, and color can be produced
according to customer requirements.
Quality certificate

Passed ISO9001, FDA, and LFGB certification.
Mass Production

Used advanced machinery and equipment to provide medical LSR with stable performance.
